1 x Self Drilling Hexagonal Head 6.3X100 Sheet...

1 x Self Drilling Hexagonal Head 6.3X100 Sheet Metal Thread Zinc Plated Ral7016/Anthracite Grey

3127151049_1
In stock 54351 Pièces
€3.50 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 100
Lot price VAT included €3.50 €7.05 €8.40 €17.65
DIN 7504K+ EMBASE CRANTEE, VS3124 - Self Drilling Hexagonal Head 6.3X100 Sheet Metal Thread Zinc Plated Ral7016/Anthracite Grey"Pierces steel
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 100 units

Dimensions shown in millimeters (mm)

Diameter
6.3
Length
100
Size Drive Type
KEY Of 10
Material
Steel
Coating
ZINGUE White
COLOR
Ral7016/Anthracite Grey
Norm
DIN 7504K+ Flange NOTCHED VS3124
Sub product family
Hex Head
Mounting pressure (N)
350
Rotation speed (rpm)
1000-1800
Minimum breaking torque (N.m)
14
Maximum thickness to be fixed
88
Head thickness
5.3-5.9
Base diameter
12.2-13.5
54351 Items
3663072480667
Self Drilling Hexagonal Head 6.3X100 Sheet Metal Thread Zinc Plated Ral7016/Anthracite Grey Other Reference : 3617500147868 3663072480667
Eric G. (vis-express.fr)
2025-11-30

Hangar cover Hangar cover 4m x 5m


Vincent D. (vis-express.fr)
2025-08-17

screwing sheets fixing roofing


Cedric a. (vis-express.fr)
2024-09-22

Fastening sheet metal type steel tray cover With special steel tray type sheet metal rider
