1 x Self Drilling Hexagonal Head 6.3X150 Sheet...

1 x Self Drilling Hexagonal Head 6.3X150 Sheet Metal Thread Zinc Plated Ral7016/Anthracite Grey

3127151549_1
In stock 1915 Pièces
€3.50 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 100
Lot price VAT included €3.50 €7.05 €9.90 €29.90
DIN 7504K+ EMBASE CRANTEE, VS3124 - Self Drilling Hexagonal Head 6.3X150 Sheet Metal Thread Zinc Plated Ral7016/Anthracite Grey"Pierces steel
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 100 units

Dimensions shown in millimeters (mm)

Diameter
6.3
Length
150
Size Drive Type
KEY Of 10
Material
Steel
Coating
ZINGUE White
COLOR
Ral7016/Anthracite Grey
Norm
DIN 7504K+ Flange NOTCHED VS3124
Sub product family
Hex Head
Mounting pressure (N)
350
Rotation speed (rpm)
1000-1800
Minimum breaking torque (N.m)
14
Head thickness
5.3-5.9
Base diameter
12.2-13.5
1915 Items
3663072071926
Self Drilling Hexagonal Head 6.3X150 Sheet Metal Thread Zinc Plated Ral7016/Anthracite Grey Other Reference : 3617500168276 3663072071926
marc c. (vis-express.fr)
2025-12-07

Fastener, tray, steel


Benedicte J. (vis-express.fr)
2025-10-26

Fixing steel tray panels to the roof


LAURENT A. (vis-express.fr)
2025-01-19

fixing a sandwich ceiling local craft office
