1 x Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black
1 x Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black
1 x Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black
1 x Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black
1 x Blind rivets Aluminium Stahlgewinde 4X18...
1 x Blind rivets Aluminium Stahlgewinde 4X18...
1 x Blind rivets Aluminium Stahlgewinde 4X18...
1 x Blind rivets Aluminium Stahlgewinde 4X18...

1 x Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black

3702401829_1
In stock 3200 Pièces
£3.34 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included £3.34 £6.68 £8.03 £22.04
Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

Dimensions shown in millimeters (mm)

Diameter
4
Sub product family
Flat Head
WEIGHT For THERE unit
2.2 GR
Clamping thickness
10 to 12 MM
Rivet body length
18
3200 Items
3663072215054

Application

  • Securing thin sheets (steel, aluminum)
  • Assembly of panels, plates or profiles
  • Aluminium joinery work
  • Installation of ventilation ducts
  • DIY, light bodywork
Blind rivets Aluminium Stahlgewinde 4X18 Thickness Of Panel 10 to 12 Flat Head Black
Diameter = 4


dimensional guide (mm)
Body diameter 2.4 3 3.2 4 4.8 6 6.4
Head diameter 5 6 6.5 8 9.5 11.5 12
Drilling diameter 2.6 3.2 3.4 4.2 5 6.2 6.6
resistance a la traction 500 800 1000 1600 2600 3800 4600
Shear strength 400 650 850 1300 2100 3000 3500
longueur tige 25 25 25 27 27 27 27 27

Other Reference : 115140181 40100090 107391 A001102 3663072215054
