1 x Machine Screw Set Screw Slotted to Tip M2X2 Stainless Steel A2 micro screw
1 x Machine Screw Set Screw Slotted to Tip M2X2 Stainless Steel A2 micro screw
1 x Machine Screw Set Screw Slotted to Tip M2X2 Stainless Steel A2 micro screw
1 x Machine Screw Set Screw Slotted to Tip M2X2...
1 x Machine Screw Set Screw Slotted to Tip M2X2...
1 x Machine Screw Set Screw Slotted to Tip M2X2...

1 x Machine Screw Set Screw Slotted to Tip M2X2 Stainless Steel A2 micro screw

8151200218_1
In stock 170 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.85 €7.70 €9.30 €27.50
DIN553,VS8151 - Machine Screw Set Screw Slotted to Tip M2X2 Stainless Steel A2 micro screw
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

Diameter
M2
Length
2
Thread
Metal
Drive Type
Slotted
Pitch
Standard pitch 40
Material
Stainless Steel Stainless Steel A2
COLOR
Grey
Norm
DIN553, VS8151
Product Family
Tip / MICROVIS
Diameter in mm
1.509 - 1.567
Unit weight
0.01 GR
170 Items
3663072472655
Machine Screw Set Screw Slotted to Tip M2X2 Stainless Steel A2 micro screw
Diameter = M2, Length = 2, Material = Stainless Steel A2, Pitch = Standard pitch 40, Drive Type = Slotted, Norm = DIN553, VS8151, Product Family = Tip / MICROVIS


dimensional guide (mm)
DiameterM1M1.2M1.4M1.6M2M2.5M3M3.5M4M5M6M8M10M12
PAS0.250.250.30.350.40.450.50.60.70.811.251.51.75
diametre pointeau0.10.120.140.160.20.250.30.350.40.51.522.53
largeur fente0.26a0.40.26a0.40.26a0.40.31a0.450.31a0.450.46a0.60.46a0.60.56a0.70.66a0.80.86a11.06a1.21.26a1.511.66a1.912.06a2.31
profondeur fente0.4a0.520.4a0.520.48a0.630.56a0.740.64a0.840.72a0.950.8a1.050.96a1.211.12a1.421.28a1.631.6a22a2.52.4a32.8a3.6

Other Reference : 0553222 3663072472655
