3702484512_1
In stock 1470 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.85 €7.70 €9.30 €49.10
Blind rivets Aluminium Stahlgewinde 4.8X45 Flat Head AL
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

Diameter
Class 4.8
Sub product family
Flat Head
WEIGHT For THERE unit
7.25 GR
Rivet body length
45
1470 Items
3663072302167

Application

  • Securing thin sheets (steel, aluminum)
  • Assembly of panels, plates or profiles
  • Aluminium joinery work
  • Installation of ventilation ducts
  • DIY, light bodywork
Blind rivets Aluminium Stahlgewinde 4.8X45 Flat Head AL
Diameter = Class 4.8


dimensional guide (mm)
Body diameter2.433.244.866.4
Head diameter566.589.511.512
Drilling diameter2.63.23.44.256.26.6
resistance a la traction50080010001600260038004600
Shear strength4006508501300210030003500
longueur tige2525252727272727

Other Reference : ASD4845 / CDE 7903 3663072302167
Philippe A. (vis-express.fr)
2025-06-15

Fixing panels Platform construction


Philippe A. (vis-express.fr)
2025-02-23

Fixing polyester panels on terrace pads Athalia brand panels on JouPlast brand pads
