1 x Caged Nut Stainless Steel Zinc Plated C4806C M6 Thickness Material 2.6 to 3.5

4336000603_1
In stock 9242 Pièces
€1.63 Incl VAT €1.85 -12%
Decreasing prices by quantity
Number of pieces 1 10 100 500 2000
Lot price VAT included €1.63 €3.26 €14.87 €61.78 €223.70
Caged Nut Stainless Steel Zinc Plated C4806C M6 Thickness Material 2.6 to 3.5
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units
  • 2000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M6
Product Family
Nut
Use
External
Grip range
2.6 to 3.5 MM
Unit weight
3.6 GR
9242 Items
3663072090934

Application

  • Assembly of metal panels.
  • Securing industrial covers and housings.
  • Automotive and bodywork.
  • Electrical and electronic equipment.
  • Metal furniture.
  • Ventilation, air conditioning and technical ducts.
  • Assembly of electrical boxes and cabinets.
Caged Nut Stainless Steel Zinc Plated C4806C M6 Thickness Material 2.6 to 3.5
Diameter = M6, Use = External, Product Family = Nut


dimensional guide (mm)
Diameter M3 M4 M4 M4 M4 M5 M5 M5 M5 M5 M6 M6 M6 M6 M6 M6 M6 M6 M6 M10 M12 M12 M12
EPAISEUR PANNEAU 1A1.6 1A1.6 2.4A3.1 1.2A1.6 1.7A2.5 1.2A1.6 1.7A2.5 2.6A3.5 3.6A4.5 0.7A1.6 1.2A1.6 1.7A2.5 2.6A3.5 3.6A4.5 1A1.7 1.8A3.2 3.3A4.7 0.7A1.6 1.7A2.7 3.3A4.7 1.8A3.2 3.3A4.7 4.8A6.2
REF. C4843B C4844B C4844D C4804A C4804B C4805A C4805B C4805C C4805D C4895A C4806A C4806B C4806C C4806D C4811A C4811B C4811C C4896A C4896B C4810C C4812B C4812C C4812D
DIMENSION CARRE 9.3 9.3 9.3 12 12 12 12 12 12 13 12 12 12 12 16 16 16 13 13 16 20 20 20
HAUTEUR 5.9 5.9 7.4 8.5 9.5 8.5 9.5 10.5 11.5 8.8 8.5 9.5 10.5 11.5 10.4 11.9 13.4 8.8 10 13.4 14.7 16.2 17.7

Other Reference : DG836C FI C4806C 0160300089 MBH3608 01980006 65247 65247 A00007732 K300230602 141087 417552 12466 12466 1.85.414.00 0300230603 VIS006EC003 QUIN0013 141087 V004607 QVVESHM8 QVVESHM8 CO521004 3663072090934
Jonathan K. (vis-express.fr)
2025-11-02

Cage nuts are mounted in folded sheet metal parts for the manufacture of boxes
