1 x Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX
1 x Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX
1 x Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX
1 x Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX
1 x Blind rivets Aluminium Stahlgewinde 3.2X14...
1 x Blind rivets Aluminium Stahlgewinde 3.2X14...
1 x Blind rivets Aluminium Stahlgewinde 3.2X14...
1 x Blind rivets Aluminium Stahlgewinde 3.2X14...

1 x Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX

3702321412_1
In stock 2980 Pièces
£3.34 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included £3.34 £6.68 £8.03 £17.40
Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

Dimensions shown in millimeters (mm)

Diameter
3.2
Sub product family
Flat Head
WEIGHT For THERE unit
1.2 GR
Clamping thickness
9 to 11 MM
Rivet body length
14
2980 Items
3663072302020

Application

  • Securing thin sheets (steel, aluminum)
  • Assembly of panels, plates or profiles
  • Aluminium joinery work
  • Installation of ventilation ducts
  • DIY, light bodywork
Blind rivets Aluminium Stahlgewinde 3.2X14 Thickness Of Panel 9 to 11 Flat Head ALX
Diameter = 3.2


dimensional guide (mm)
Body diameter2.433.244.866.4
Head diameter566.589.511.512
Drilling diameter2.63.23.44.256.26.6
resistance a la traction50080010001600260038004600
Shear strength4006508501300210030003500
longueur tige2525252727272727

Other Reference : 103132141 3310 641000132135 CO220033 3663072302020
