1 x Washer Split Lock Stainless Steel A2 Linch Pin Screw M8

1 x Washer Split Lock Stainless Steel A2 Linch Pin Screw M8

Name: 1 x Washer Split Lock Stainless Steel A2 Linch Pin Screw M8
Brand: Screw Express
SKU: 8551000818
Price: 1.39 GBP
Availability: InStock

Reference 8551000818_1

In stock 25281 Pièces

£1.39 Incl VAT

Decreasing prices by quantity

Number of pieces	1	10	30	200
Lot price VAT included	£1.39	£2.78	£3.38	£3.64

Washer Split Lock Stainless Steel A2 Linch Pin Screw M8

Packaging

1 unit
10 units
30 units
200 units

Dimensions shown in millimeters (mm)

Product Details

Diameter: M8
Thickness: MM
Linch Pin Screw: M8
Material: Stainless Steel Stainless Steel A2
COLOR: Grey
Norm: VS-DIN127B
Unit weight: 1 GR

In stock 25281 Items

ean13 3663072569218

Description

Washer Split Lock Stainless Steel A2 Linch Pin Screw M8
Diameter = M8, Thickness = MM, Material = Stainless Steel Stainless Steel A2, Norm = VS-DIN127B

dimensional guide (mm)

Diameter	M3	M4	M5	M6	M7	M8	M10	M12	M14	M16	M18	M20	M24	M27	M30	M36	M39	M42	M45	M48
Interior diameter	3.1	4.1	5.1	6.1	7.1	8.1	10.2	12.2	14.2	16.2	18.2	20.2	24.5	27.5	30.5	36.5	39.5	42.5	45.5	49
Exterior diameter	6.2	7.6	9.2	11.8	12.8	14.8	18.1	21.1	24.1	27.4	29.4	33.6	40	43	48.2	58.2	61.2	68.2	71.2	75
Tickness	0.8	0.9	1.2	1.6	1.6	2	2.2	2.5	3	3.5	3.5	4	5	5	6	6	6	7	7	7
