1 x Self Drilling Stainless Steel A2 Cylindrical Button Head Pozi 3.9X16
1 x Self Drilling Stainless Steel A2 Cylindrical Button Head Pozi 3.9X16
1 x Self Drilling Stainless Steel A2 Cylindrical Button Head Pozi 3.9X16
1 x Self Drilling Stainless Steel A2...
1 x Self Drilling Stainless Steel A2...
1 x Self Drilling Stainless Steel A2...

1 x Self Drilling Stainless Steel A2 Cylindrical Button Head Pozi 3.9X16

8326701618_1
In stock 28281 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.85 €7.70 €9.30 €10.00
DIN 7504 N,VS3124 - Self Drilling Stainless Steel A2 Cylindrical Button Head Pozi 3.9X16
Only pierces aluminum
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

Diameter
3.9
Length
16
Size Drive Type
KEY Of 5.5
Material
Stainless Steel Stainless Steel A2
COLOR
Grey
Norm
DIN 7504 N,VS3124
Sub product family
Cylindrical Head Pan Head
Mounting pressure (N)
150
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
3.4
Maximum thickness to be fixed
Class 8.8
Unit weight
1.46 GR
Material to be drilled
Aluminium
28281 Items
3663072153653
Self Drilling Stainless Steel A2 Cylindrical Button Head Pozi 3.9X16
Diameter = 3.9, Length = 16, Material = Stainless Steel A2, Norm = DIN 7504 N,VS3124, Size Drive Type = Spanner 5.5


dimensional guide (mm)
Jauge number67810
Diameter3.53.94.24.8
Pitch6.97.58.29.5
Head Tickness2.62.83.053.55
Pozi1222

Other Reference : 624303,9X16 MP09655 302001 GNQ000007 2102AU0001 021113916 S100401 152116-CH ZAPE23916 2102AU0001 31488 9150836 9150836 3663072153653
