8326601618_1
In stock 15570 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.85 €7.70 €9.30 €10.00
DIN 7504 N,VS3124 - Self Drilling Stainless Steel A2 Cylindrical Button Head Phillips 3.5X16
Only pierces aluminum
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

Diameter
3.5
Length
16
Drive Type
PHILLIPS
Size Drive Type
KEY Of 5.5
Material
Stainless Steel Stainless Steel A2
COLOR
Grey
Norm
DIN 7504 N,VS3124
Sub product family
Cylindrical Head Pan Head
Mounting pressure (N)
150
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
2.8
Maximum thickness to be fixed
9.2
Unit weight
1.22 GR
Material to be drilled
Aluminium
15570 Items
3663072183612
Self Drilling Stainless Steel A2 Cylindrical Button Head Phillips 3.5X16
Diameter = 3.5, Length = 16, Material = Stainless Steel A2, Drive Type = PHILLIPS, Norm = DIN 7504 N,VS3124, Size Drive Type = Spanner 5.5


dimensional guide (mm)
Jauge number67810
Diameter3.53.94.24.8
Pitch6.97.58.29.5
Head Tickness2.62.83.053.55
Pozi1222

Other Reference : 75042M35 16 3663072183612
