3138802502_1
In stock 46106 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included €3.85 €7.70 €9.25 €10.00
DIN 7504P+ CARRE,VS3124 - Self Drilling Countersunk Head EMP Square Square 2 4.2X25 Zinc Plated
"Pierces steel
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

Dimensions shown in millimeters (mm)

Diameter
4.2
Length
25
Drive Type
Square
Size Drive Type
Square 2
Material
Steel
Coating
ZINC White
COLOR
Grey
Norm
DIN 7504P+ SQUARE, VS3124
Sub product family
Countersunk Head
WEIGHT For THERE unit
1.7 GR
Mounting pressure (N)
250
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
4.5
Maximum thickness to be fixed
16.3
46106 Items
3663072041578
Self Drilling Countersunk Head EMP Square Square 2 4.2X25 Zinc Plated
Diameter = 4.2, Length = 25, Coating = Zinc Plated, Material = Steel, Drive Type = Square, Norm = DIN 7504P+ SQUARE,VS3124, Size Drive Type = Square 2


dimensional guide (mm)
Jauge number8
Diameter4.2
Head diameter8.1
Head Tickness2.5
SQ2

Other Reference : TFQ42025 U09925-02500 U09925-02500 U09925-02500 971455000 9744050 497739900 971455000 3663072041578
