1 x Machine Screw Socket Head M10X50 Thread Length: 32 Hexagon Socket 8 Stainless Steel A4
1 x Machine Screw Socket Head M10X50 Thread Length: 32 Hexagon Socket 8 Stainless Steel A4
1 x Machine Screw Socket Head M10X50 Thread...
1 x Machine Screw Socket Head M10X50 Thread...

1 x Machine Screw Socket Head M10X50 Thread Length: 32 Hexagon Socket 8 Stainless Steel A4

8820105018_1
In stock 444 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 5 20 50
Lot price VAT included €3.85 €7.70 €12.30 €28.10
DIN 912 ISO 4762 - Machine Screw Socket Head M10X50 Thread Length: 32 Hexagon Socket 8 Stainless Steel A4
Packaging
  • 1 unit
  • 5 units
  • 20 units
  • 50 units

Dimensions shown in millimeters (mm)

Diameter
M10
Length
50
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 8
Pitch
Standard pitch 150
Material
Stainless Steel A4
COLOR
Grey
Norm
DIN 912 ISO 4762
Product Family
Machine Screw
Sub product family
Head Socket Head BTR
Diameter in mm
9.968 - 9.752
Unit weight
39.3 GR
444 Items
3663072419308
Machine Screw Socket Head M10X50 Thread Length: 32 Hexagon Socket 8 Stainless Steel A4
Diameter = M10, Length = 50, Material = Stainless Steel A4, Pitch = Standard pitch 150, Drive Type = Socket Cap, Norm = DIN 912 ISO 4762, Product Family = Machine Screw, Size Drive Type = Hexagon Socket 8


dimensional guide (mm)
Diameter M1.4 M1.6 M2 M2.5 M3 M4 M5 M6 M7 M8 M10 M12 M14 M16 M18 M20 M22 M24 M27 M30 M33 M36 M42 M48 M56
Across flats 1.3 1.5 1.5 2 2.5 3 4 5 6 6 8 10 12 14 14 17 17 19 19 22 24 27 32 36 41
Head diameter 2.6 3 3.8 4.5 5.5 7 8.5 10 12 13 16 18 21 24 27 30 33 36 40 45 50 54 63 72 84
Head tickness 1.4 1.6 2 2.5 3 4 5 6 7 8 10 12 14 16 18 20 22 24 27 30 33 36 42 48 56
Thread length 14 15 16 17 18 20 22 24 26 28 32 36 40 44 48 52 56 60 66 72 78 84 96 108 124

Other Reference : 6420110X50 9A-1553044 PVVSC0 VISINOA4CHCM 338029 VIS000035 3663072419308
