1 x Self Drilling Countersunk Head T25 5.5X38 Notched And Wings Zinc Plated

3126123802_1
In stock 54970 Pièces
€1.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 250 1000
Lot price VAT included €1.85 €3.70 €4.50 €10.75 €40.80
DIN7504+6LOB+CR+AIL,VS3126,VS3124 - Self Drilling Countersunk Head T25 5.5X38 Notched And Wings Zinc Plated
"Pierces steel
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 250 Units
  • 1000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
5.5
Length
38
Drive Type
Torx
Size Drive Type
T25
Material
Steel
Coating
ZINC White
COLOR
Grey
Norm
DIN7504+6LOB+CR+AIL,VS3126,VS3124
Sub product family
Countersunk Head
WEIGHT For THERE unit
6 GR
Mounting pressure (N)
350
Rotation speed (rpm)
1000-1800
Minimum breaking torque (N.m)
10
Maximum thickness to be fixed
27.5
54970 Items
3663072276314
Self Drilling Countersunk Head T25 5.5X38 Notched And Wings Zinc Plated
Diameter = 5.5, Length = 38, Coating = Zinc Plated, Material = Steel, Drive Type = Torx, Norm = DIN7504+6LOB+CR+AIL,VS3126,VS3124, Size Drive Type = T25


dimensional guide (mm)
Jauge number 12 14
Diameter 5.5 6.3
Head diameter 10.8 12.4
Head Tickness 3.4 3.8
Tx 30 30

Other Reference : 3617501737884 AR00784 13A0110 3663072276314
