1 x Machine Screw Hexagonal Head 3/8X 1" Unf Grade 5 Zinc Plated

4128102602_1
In stock 5084 Pièces
£1.48 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100
Lot price VAT included £1.48 £2.95 £6.38
ANSI B18-2-1,VS4126 - Machine Screw Hexagonal Head 3/8X 1" Unf Grade 5 Zinc Plated
1 inch = 25.4mm
Packaging
  • 1 unit
  • 10 units
  • 100 units

Correspondence table inches and mm

Diameter
3/8
Length
1"25,4
Thread
Metal
Pitch
Pitch Unf
Material
Steel
Coating
Zinc Plated
COLOR
Grey
Product Family
Screw AMERICANS
Number of threads per inch
24
Diameter in mm
9,525
Unit weight
21.3 GR
Head shape
Hex Head
5084 Items
3663072082731
Machine Screw Hexagonal Head 3/8X 1" Unf Grade 5 Zinc Plated
Diameter = 3/8, Length = 1"25.4, Coating = Zinc Plated, Material = Steel, Pitch = Pitch Unf, Product Family = Screw AMERICANS


dimensional guide (mm)
DIAMETRE en pouce 1/4 5/16 3/8 7/16 1/2 5/8 3/4 7/8 1
Head Tickness 0.158 0.206 0.238 0.286 0.318 0.398 0.473 0.553 0.617
Across flats 0.4375 0.5 0.5625 0.625 0.75 0.9375 1.125 1.3125 1.5
PAS UNF(nbre de filets au pouce (sur 25.4mm)) 28 24 24 20 20 18 16 14 12
1 pouce = 25.4 mm

Other Reference : 3617500950741 0300060302 0300060302 0300060302 3663072082731
Rémi R. (vis-express.fr)
2025-12-07

For replacement on Lifan motor Lost screw!
