1 x Self Drilling Pan Head Square 2 4.2X13 Zinc...

1 x Self Drilling Pan Head Square 2 4.2X13 Zinc Plated With 1 Bit Length 50

3172801402_1
In stock 39354 Pièces
£3.69 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included £3.69 £7.33 £8.81 £15.53
DIN 7504N With Serration Square - Self Drilling Pan Head Square 2 4.2X13 Zinc Plated With 1 Bit Length 50
Pierces steel stainless steel and aluminum
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
4.2
Length
13
Drive Type
Square
Size Drive Type
Square 2
Material
Steel
Coating
ZINC White
COLOR
Grey
Norm
DIN 7504N+ CR+SQ,VS3124
Sub product family
Cylindrical Head
WEIGHT For THERE unit
1.4 GR
Mounting pressure (N)
250
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
4.5
Maximum thickness to be fixed
4.3
39354 Items
3663072043930
Self Drilling Pan Head Square 2 4.2X13 Zinc Plated With 1 Bit Length 50
Diameter = 4.2, Length = 13, Coating = White zinc plated, Material = Steel, Drive Type = Square, Norm = DIN 7504N With Serration SQ,VS3124, Product Family = Self Drilling, Size Drive Type = Square 2


dimensional guide (mm)
numero67810
Diameter3.53.94.24.8
Head diameter6.97.58.29.5
Head Tickness2.62.83.53.55
SQ1222

Other Reference : 3617501913400 VIS4-0004 904831 VIS4213CARRE VISVISTC0420 VIS4.213 201730 VATBEC4213 32300109 3663072043930
