1 x Self Drilling Pan Head Square 2 4.2X13 Zinc...

1 x Self Drilling Pan Head Square 2 4.2X13 Zinc Plated With 1 Bit Length 50

3172801402_1
In stock 86180 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included €4.25 €8.45 €10.15 €17.90
DIN 7504N+ CR+SQ,VS3124 - Self Drilling Pan Head Square 2 4.2X13 Zinc Plated With 1 Bit Length 50
"Pierces steel
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
4.2
Length
13
Drive Type
Square
Size Drive Type
Square 2
Material
Steel
Coating
ZINC White
COLOR
Grey
Norm
DIN 7504N+ CR+SQ,VS3124
Sub product family
Cylindrical Head
WEIGHT For THERE unit
1.4 GR
Mounting pressure (N)
250
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
4.5
Maximum thickness to be fixed
4.3
86180 Items
3663072043930
Self Drilling Pan Head Square 2 4.2X13 Zinc Plated With 1 Bit Length 50
Diameter = 4.2, Length = 13, Coating = Zinc Plated, Material = Steel, Drive Type = Square, Norm = DIN 7504N+ CR+SQ,VS3124, Size Drive Type = Square 2


dimensional guide (mm)
numero 6 7 8 10
Diameter 3.5 3.9 4.2 4.8
Head diameter 6.9 7.5 8.2 9.5
Head Tickness 2.6 2.8 3.5 3.55
SQ 1 2 2 2

Other Reference : 3617501913400 VIS4-0004 904831 VIS4213CARRE VISVISTC0420 VIS4.213 201730 VATBEC4213 32300109 3663072043930
