1 x Self Drilling Pan Head Square 2 4.2X16 Zinc...

1 x Self Drilling Pan Head Square 2 4.2X16 Zinc Plated With 1 Bit Length 50

3172801702_1
In stock 312170 Pièces
£3.69 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included £3.69 £7.33 £8.81 £13.54
DIN 7504N+ CR+SQ,VS3124 - Self Drilling Pan Head Square 2 4.2X16 Zinc Plated With 1 Bit Length 50
"Pierces steel
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
4.2
Length
16
Drive Type
Square
Size Drive Type
Square 2
Material
Steel
Coating
ZINC White
COLOR
Grey
Norm
DIN 7504N+ CR+SQ,VS3124
Sub product family
Cylindrical Head
WEIGHT For THERE unit
1.72 GR
Mounting pressure (N)
250
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
4.5
Maximum thickness to be fixed
7.3
312170 Items
3663072043947
Self Drilling Pan Head Square 2 4.2X16 Zinc Plated With 1 Bit Length 50
Diameter = 4.2, Length = 16, Coating = Zinc Plated, Material = Steel, Drive Type = Square, Norm = DIN 7504N+ CR+SQ,VS3124, Size Drive Type = Square 2


dimensional guide (mm)
numero 6 7 8 10
Diameter 3.5 3.9 4.2 4.8
Head diameter 6.9 7.5 8.2 9.5
Head Tickness 2.6 2.8 3.5 3.55
SQ 1 2 2 2

Other Reference : 3617501907904 173719 61990 VIS4216CARRE 3305 M6580 VAH42016 VATBEC4216 3663072043947
