1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 6 M12X40 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 6 M12X40 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 6 M12X40 Flat Point Zinc Plated

4616124002_1
In stock 404 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 100
Lot price VAT included €4.25 €8.45 €25.20 €84.10
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 6 M12X40 Flat Point Zinc Plated
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 100 units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M12
Length
40
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 6
Pitch
Standard pitch 175
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN 913
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
11,966 - 11,718
Unit weight
26.1 GR
404 Items
3663072209947
Machine Screw Socket Head Hexagon Recess Hexagon Socket 6 M12X40 Flat Point Zinc Plated
Diameter = M12, Length = 40, Coating = Zinc Plated, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 175, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 6


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501268647 3663072209947
