8419801418_1
In stock 5370 Pièces
€1.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200 800
Lot price VAT included €1.85 €3.70 €4.50 €24.60 €93.20
ISO 10642 Similar DIN7991 - Machine Screw Stainless Steel A2 Flat Head Hexagon Recess Hexagon Socket 5 M8X14 SS MARQ HEAD Full Thread
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units
  • 800 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M8
Length
14
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 5
Pitch
Standard pitch 125
Diameter Head
15,24-17,92
Material
Stainless Steel A2
COLOR
Grey
Norm
ISO10642 Similar DIN7991 Full Thread
Product Family
Machine Screw
Diameter in mm
7.972 - 7.772
Unit weight
7.5 GR
Head shape
Head Flat Head Hexagon Recess
Hole diameter
9,0
Pre-drilling
6.8
5370 Items
3663072164673
Machine Screw Stainless Steel A2 Flat Head Hexagon Recess Hexagon Socket 5 M8X14 SS MARQ HEAD Full Thread
Diameter = M8, Length = 14, Material = Stainless Steel A2, Pitch = Standard pitch 125, Drive Type = Socket Cap, Norm = ISO10642 Similar DIN7991 Full Thread, Product Family = Machine Screw, Size Drive Type = Hexagon Socket 5


dimensional guide (mm)
Diameter M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 2 2.5 3 4 5 6 8 10 10 12 12 14 14
Head diameter 6 8 10 12 16 20 24 27 30 33 36 36 39
Thread length for screw L<125 12 14 16 18 22 26 30 34 38 42 46 50 54
Thread length for screw 125 - - - 24 28 32 36 40 44 48 52 56 60
Thread length for screw L>200 - - - - - 45 49 53 57 61 65 69 73
L=LONGUEUR

Other Reference : 3617500224873 134856 5VINOX8X14 VISA2FHC08X1 EV38 EV38 00688 00688 00688 3663072164673
