3701320812_1
In stock 20713 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included €4.25 €8.45 €10.15 €28.10
Blind rivets Aluminium Stahlgewinde 3.2X8 Thickness Of Panel 3 to 5 Countersunk Head ALX
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

Dimensions shown in millimeters (mm)

Diameter
3.2
Diameter Head
6.5
Material
BODY Aluminium / rod Steel
Sub product family
Rivets BLIND STANDARDS (USE GENERAL)
Shear (N)
500
Clamping thickness
3 a 5 mm
Rivet body length
8
Unit weight
1 GR
Head shape
Countersunk Head
Hole diameter
3.4
Tensile strength
700
20713 Items
3663072063600

Application

  • bodywork
  • metal cladding
  • aluminium joinery
  • equipment requiring a smooth surface
Blind rivets Aluminium Stahlgewinde 3.2X8 Thickness Of Panel 3 to 5 Countersunk Head ALX
Diameter = 3.2, Sub Product Family = Rivets BLIND STANDARDS (USE GENERAL), Material = BODY Aluminium / rod Steel, Diameter Head = 6.5


dimensional guide (mm)
Body diameter 2.4 3 3.2 4 4.8
Head diameter 5 6 6.5 8 9.5
Drilling diameter 2.6 3.2 3.4 4.2 5
resistance a la traction 500 800 1000 1600 2600
Shear strength 400 650 850 1300 2100
The length indicates the length of the body (useful length)
tete fraisee a 120 degres

Other Reference : 103432081 0RIV0002 221145 021.R.ALXRF 202110002 100624 SSTDDI00001 024331 RIVTF3.2X8 3663072063600
Blinder B. (vis-express.fr)
2025-12-07

rivets used for motorcycle fairing fixings used to fix female dzus riveted plates.
