8330701318_1
In stock 7 Pièces
£3.34 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included £3.34 £6.68 £8.03 £21.78
DIN 7504 O,VS3124 - Self Drilling Stainless Steel A2 Countersunk Head Square 3.9X13 Square 1
Only pierces aluminum
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

Dimensions shown in millimeters (mm)

Diameter
3.9
Length
13
Drive Type
Square
Size Drive Type
Square 1
Material
Stainless Steel Stainless Steel A2
COLOR
Grey
Norm
DIN 7504 O,VS3124
Sub product family
Countersunk Head
Mounting pressure (N)
150
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
3.4
Maximum thickness to be fixed
5.8
Unit weight
1.02 GR
Material to be drilled
Aluminium
7 Items
3663072154315
Self Drilling Stainless Steel A2 Countersunk Head Square 3.9X13 Square 1
Diameter = 3.9, Length = 13, Material = Stainless Steel A2, Drive Type = Square, Norm = DIN 7504 O,VS3124, Size Drive Type = Square 1


dimensional guide (mm)
diametre3.94.24.8
Head diameter7.58.19.5
Head Tickness2.32.53
sq222

Other Reference : 3617501955936 8330701318 3663072154315
