1 x Self Drilling Cylindrical Button Head Phillips 3.5X13 Sheet Metal Thread Zinc Plated
1 x Self Drilling Cylindrical Button Head Phillips 3.5X13 Sheet Metal Thread Zinc Plated
1 x Self Drilling Cylindrical Button Head...
1 x Self Drilling Cylindrical Button Head...

1 x Self Drilling Cylindrical Button Head Phillips 3.5X13 Sheet Metal Thread Zinc Plated

3125601302_1
In stock 273159 Pièces
£1.39 Incl VAT
Decreasing prices by quantity
Number of pieces 1 100 200 1000
Lot price VAT included £1.39 £3.34 £3.64 £6.77
DIN 7504N + CR - VS3124 - Self Drilling Cylindrical Button Head Phillips 3.5X13 Sheet Metal Thread Zinc Plated"Pierces steel
Packaging
  • 1 unit
  • 100 units
  • 200 units
  • 1000 units

Dimensions shown in millimeters (mm)

Diameter
3.5
Length
13
Drive Type
PHILLIPS
Material
Steel
Coating
ZINC White
COLOR
Grey
Norm
DIN 7504N + With Serration - VS3124
Sub product family
Cylindrical Head Pan Head
WEIGHT For THERE unit
1.01 GR
Mounting pressure (N)
150
Rotation speed (rpm)
1800-2500
Minimum breaking torque (N.m)
2.8
Maximum thickness to be fixed
6.2
273159 Items
3663072038707
Self Drilling Cylindrical Button Head Phillips 3.5X13 Sheet Metal Thread Zinc Plated Other Reference : TCC35013 6410104 1828A10 103327 1828A10 1828A10 1830A10 VAATCP3513 AUTOPER13 VI092527 QC0704 QC0704 AR00767 6301681 01828A10.0 VISAUTOPZ VISAUTOPZ 20000 504013513 103327 A52011 VIS096 W110018 A00831 VISTCB3.5X13 0938238100 9VATCPH13513 A100485 VISA/FTC3.5X APTRPF13 VIS096 MP015009 40287 VIO92527 VTAP35X13 02113513 103327 /AN 7504/305X13Z 607211 607211 MVVA3513C 5 CV 20008 PU01914 021135 13 731433 6301681 3663072038707
Vincsnt M. (vis-express.fr)
2025-12-21

Metal frame fixing and stud reinforcement placo partition wall with metal rail and stud reinforcement


arnaud c. (vis-express.fr)
2024-07-14

drill a thin sheet metal the screws will be used to drill aluminum for installing the gutter
