1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Socket 4 M5X14 Full Thread
1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Socket 4 M5X14 Full Thread
1 x Machine Screw Stainless Steel A2 Socket...
1 x Machine Screw Stainless Steel A2 Socket...

1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Socket 4 M5X14 Full Thread

8420501418_1
In stock 23783 Pièces
£1.61 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200 800
Lot price VAT included £1.61 £3.21 £3.91 £10.33 £39.22
DIN 912 ISO 4762 - Machine Screw Stainless Steel A2 Socket Head Hexagon Socket 4 M5X14 Full Thread
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units
  • 800 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M5
Length
14
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 4
Pitch
Standard pitch 80
Diameter Head
8,28 - 8,50
Material
Stainless Steel A2
COLOR
Grey
Norm
DIN 912 ISO 4762
Product Family
Machine Screw
Head thickness
4,82 - 5,00
Diameter in mm
4.976 - 4.826
Unit weight
3.14 GR
Head shape
Head Socket Head
Minimum recess depth
2.50
23783 Items
3663072211674
Machine Screw Stainless Steel A2 Socket Head Hexagon Socket 4 M5X14 Full Thread
Diameter = M5, Length = 14, Material = Stainless Steel A2, Pitch = Standard pitch 80, Drive Type = Socket Cap, Norm = DIN 912 ISO 4762, Product Family = Machine Screw, Size Drive Type = Hexagon Socket 4


dimensional guide (mm)
Diameter M1.4 M1.6 M2 M2.5 M3 M4 M5 M6 M7 M8 M10 M12 M14 M16 M18 M20 M22 M24 M27 M30 M33 M36 M42 M48 M56
Across flats 1.3 1.5 1.5 2 2.5 3 4 5 6 6 8 10 12 14 14 17 17 19 19 22 24 27 32 36 41
Head diameter 2.6 3 3.8 4.5 5.5 7 8.5 10 12 13 16 18 21 24 27 30 33 36 40 45 50 54 63 72 84
Head tickness 1.4 1.6 2 2.5 3 4 5 6 7 8 10 12 14 16 18 20 22 24 27 30 33 36 42 48 56
Thread length 14 15 16 17 18 20 22 24 26 28 32 36 40 44 48 52 56 60 66 72 78 84 96 108 124

Other Reference : 622015X14 14967 901013164 0225628 MVISINO00161 182044 106048 06000750 3663072211674
NICOLAS P. (vis-express.fr)
2025-12-14

glass clamp fixing for guardrails
