1 x Machine Screw Hexagonal Head 7/16X 1" Unf Grade 5 Steel

1 x Machine Screw Hexagonal Head 7/16X 1" Unf...

1 x Machine Screw Hexagonal Head 7/16X 1" Unf Grade 5 Steel

Name: 1 x Machine Screw Hexagonal Head 7/16X 1" Unf Grade 5 Steel
Brand: Screw Express
SKU: 4128112501
Price: 3.34 GBP
Availability: InStock

Reference 4128112501_1

In stock 123 Pièces

£3.34 Incl VAT

Decreasing prices by quantity

Number of pieces	1	10	30	200
Lot price VAT included	£3.34	£19.35	£58.05	£386.84

ANSI B18-2-1,VS4126 - Machine Screw Hexagonal Head 7/16X 1" Unf Grade 5 Steel
1 inch = 25.4mm

Packaging

1 unit
10 units
30 units
200 units

Correspondence table inches and mm

Product Details

Diameter: 7/16
Length

Length

How do I measure the length of a screw?

The length of a countersunk screw is measured with the head. For all other heads, the length is measured under the head.: 1"25,4
Thread: Metal
Pitch: Pitch Unf
Material: Steel
COLOR: Grey Steel / Black
Product Family: Screw AMERICANS
Number of threads per inch

Number of threads per inch

How to determine the diameter of a UNC or UNF screw:

The number of threads per inch will determine the diameter of the screw or nut of an American UNC or UNF screw.

Simply count the number of threads per inch (i.e. 25.4 mm) and refer to the table below.

For diameter 1 inch: 8 threads for 1 inch (25.4 mm) = UNC THREAD

Ø in inches

Ø in mm

Number of threads/inch in UNC

Number of threads/inch in UNF (fine pitch)

N°0

1.524

80

N°1

1.854

64

72

N°2

2.184

56

64

N°3

2.515

48

56

N°4

2.845

40

48

N°5

3.175

40

44

N°6

3.505

32

40

N°8

4.166

32

36

N°10

4.826

24

32

N°12

5.486

24

28

1/4

6.35

20

28

5/16

7.938

18

24

3/8

9.525

16

24

7/16

11.113

14

20

1/2

12.7

13

20

9/16

14.288

12

18

5/8

15.875

11

18

3/4

19.05

10

16

7/8

22.225

9

14

1”

25.4

8

14

1”1/8

28.575

7

12

1”1/4

31.75

7

12

1“1/2

38.1

6

12

1”3/4

44.45

5

-: 20
Diameter in mm: 11,113
Unit weight: 28.7 GR
Head shape: Hex Head

In stock 123 Items

ean13 3663072198661

Description

Machine Screw Hexagonal Head 7/16X 1" Unf Grade 5 Steel
Diameter = 7/16, Length = 1"25.4, Material = Steel, Pitch = Pitch Unf, Product Family = Screw AMERICANS

dimensional guide (mm)

DIAMETRE en pouce	1/4	5/16	3/8	7/16	1/2	5/8	3/4	7/8	1
Head Tickness	0.158	0.206	0.238	0.286	0.318	0.398	0.473	0.553	0.617
Across flats	0.4375	0.5	0.5625	0.625	0.75	0.9375	1.125	1.3125	1.5
PAS UNF(nbre de filets au pouce (sur 25.4mm))	28	24	24	20	20	18	16	14	12
1 pouce = 25.4 mm

Other Reference : 3473576740842 K300060701 K300060701 K300060701 K300060701 3663072198661
