1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X10 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X10 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X10 Flat Point Zinc Plated

4616101002_1
In stock 7155 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included €4.25 €8.45 €10.15 €40.10
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X10 Flat Point Zinc Plated
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M10
Length
10
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 5
Pitch
Standard pitch 150
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN 913
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
9.968 - 9.752
Unit weight
4.6 GR
7155 Items
3663072101586
Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X10 Flat Point Zinc Plated
Diameter = M10, Length = 10, Coating = Zinc Plated, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 150, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 5


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501923652 2VISTH005 2VISTH005 3002067 9A-1503556 01K080 P0119994 CO85301.006 6030205 3663072101586
