1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X16 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X16 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X16 Flat Point Zinc Plated

4616101602_1
In stock 4286 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.85 €7.70 €9.30 €35.50
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X16 Flat Point Zinc Plated
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

Diameter
M10
Length
16
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 5
Pitch
Standard pitch 150
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN 913
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
9.968 - 9.752
Unit weight
6.78 GR
4286 Items
3663072219298
Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X16 Flat Point Zinc Plated
Diameter = M10, Length = 16, Coating = Zinc Plated, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 150, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 5


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501064935 1140196 STHC10 3002165 9A-1503557 263441 913M10X16AZ RAVV03Z-1016 VSTHC1016PL 006654 241882 3663072219298
Adrien G. (vis-express.fr)
2024-10-06

I glue them into plaster molds to make custom hardware!
