1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X100 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X100 Flat Point Zinc Plated
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X100 Flat Point Zinc Plated

4616111002_1
In stock 88 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 5 20 50
Lot price VAT included €4.25 €10.80 €43.10 €107.80
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X100 Flat Point Zinc Plated
Packaging
  • 1 unit
  • 5 units
  • 20 units
  • 50 units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M10
Length
100
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 5
Pitch
Standard pitch 150
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN 913
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
9.968 - 9.752
Unit weight
47.4 GR
88 Items
3663072373365
Machine Screw Socket Head Hexagon Recess Hexagon Socket 5 M10X100 Flat Point Zinc Plated
Diameter = M10, Length = 100, Coating = Zinc Plated, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 150, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 5


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501752139 408526 VISO.STHC.10 6030204 3663072373365
