1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X3 Flat Point Steel micro screw
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X3 Flat Point Steel micro screw
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X3 Flat Point Steel micro screw
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X3 Flat Point Steel micro screw

4616300301_1
In stock 4300 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included €4.25 €8.45 €10.15 €25.10
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X3 Flat Point Steel micro screw
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M3
Length
3
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 1.5
Pitch
Standard pitch 50
Material
Steel
COLOR
Grey Steel / Black
Norm
DIN 913
Product Family
Screw Set Screw / MICROVIS
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
2.974 - 2.835
Unit weight
0.08 GR
4300 Items
3663072209954
Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X3 Flat Point Steel micro screw
Diameter = M3, Length = 3, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 50, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw / MICROVIS, Size Drive Type = Hexagon Socket 1.5


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501922884 VB HC303 QC1362 VISMASTHC3X0 5-590029 7291 06HCM3X3 7103000303 3663072209954
ERIC C. (vis-express.fr)
2025-12-07

Mounting of bevel gears on 5mm diameter shafts Mounting of a gearbox for a VARIO brand model helicopter mechanics
