1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X4 Flat Point Zinc Plated micro screw
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X4 Flat Point Zinc Plated micro screw
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X4 Flat Point Zinc Plated micro screw

4616300402_1
In stock 1767 Pièces
£3.69 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 1000
Lot price VAT included £3.69 £7.33 £8.81 £30.37
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X4 Flat Point Zinc Plated micro screw
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 1000 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M3
Length
4
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 1.5
Pitch
Standard pitch 50
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN 913
Product Family
Screw Set Screw / MICROVIS
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
2.974 - 2.835
Unit weight
0.12 GR
1767 Items
3663072101876
Machine Screw Socket Head Hexagon Recess Hexagon Socket 1.5 M3X4 Flat Point Zinc Plated micro screw
Diameter = M3, Length = 4, Coating = Zinc Plated, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 50, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw / MICROVIS, Size Drive Type = Hexagon Socket 1.5


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501923713 7031 VIAG0038 P0406 3663072101876
Christophe L. (vis-express.fr)
2025-03-16

Use in point screws on 3D prints Implementation in molded brass inserts in 3D prints
