1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 3 M6X60 Flat Point Steel
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 3 M6X60 Flat Point Steel
1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 3 M6X60 Flat Point Steel
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...
1 x Machine Screw Socket Head Hexagon Recess...

1 x Machine Screw Socket Head Hexagon Recess Hexagon Socket 3 M6X60 Flat Point Steel

4616606001_1
In stock 377 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.85 €7.70 €10.05 €66.80
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 3 M6X60 Flat Point Steel
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

Diameter
M6
Length
60
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 3
Pitch
Standard pitch 100
Material
Steel
COLOR
Grey Steel / Black
Norm
DIN 913
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
5.974 - 5.794
Unit weight
10 GR
377 Items
3663072374348
Machine Screw Socket Head Hexagon Recess Hexagon Socket 3 M6X60 Flat Point Steel
Diameter = M6, Length = 60, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 100, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 3


dimensional guide (mm)
Diameter M1.4 M1.6 M1.8 M2 M2.5 M3 M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
Across flats 0.7 0.7 0.7 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12

Other Reference : 3617501236424 5150066 5150066 MPVIS00223 MPVIS00223 51902 3663072374348
