4616801601_1
In stock 3373 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included €3.85 €7.70 €12.40 €50.90
DIN 913 - Machine Screw Socket Head Hexagon Recess Hexagon Socket 4 M8X16 Flat Point Steel
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

Dimensions shown in millimeters (mm)

Diameter
M8
Length
16
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 4
Pitch
Standard pitch 125
Material
Steel
COLOR
Grey Steel / Black
Norm
DIN 913
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Flat Point
Diameter in mm
7.972 - 7.772
Unit weight
4.4 GR
3373 Items
3663072102422
Machine Screw Socket Head Hexagon Recess Hexagon Socket 4 M8X16 Flat Point Steel
Diameter = M8, Length = 16, Sub Product Family = Set Screw HEXA. With Hole, Material = Steel, Pitch = Standard pitch 125, Drive Type = Socket Cap, Norm = DIN 913, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 4


dimensional guide (mm)
DiameterM1.4M1.6M1.8M2M2.5M3M4M5M6M8M10M12M14M16M18M20M22M24
Across flats0.70.70.70.91.31.522.534566810101212

Other Reference : 0000023771 0910012 0910012 VI410080163 1905999 V03-816 00277840 STHCM8X16 11076 0255815 21463067 06HCPLM8X16 3663072102422
FLORIAN J. (vis-express.fr)
2026-01-18

sthc to hold the cylinder rod fixing before welding
