1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Recess Hexagon Socket 4 M8X8 Cone Point
1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Recess Hexagon Socket 4 M8X8 Cone Point
1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Recess Hexagon Socket 4 M8X8 Cone Point
1 x Machine Screw Stainless Steel A2 Socket...
1 x Machine Screw Stainless Steel A2 Socket...
1 x Machine Screw Stainless Steel A2 Socket...

1 x Machine Screw Stainless Steel A2 Socket Head Hexagon Recess Hexagon Socket 4 M8X8 Cone Point

8418800818_1
In stock 1579 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €4.25 €8.45 €10.20 €11.20
DIN 914 ISO 4027 - Machine Screw Stainless Steel A2 Socket Head Hexagon Recess Hexagon Socket 4 M8X8 Cone Point
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M8
Length
8
Thread
Metal
Drive Type
Socket Cap
Size Drive Type
Hexagon Socket 4
Pitch
Standard pitch 125
Material
Stainless Steel Stainless Steel A2
COLOR
Grey
Norm
DIN 914 ISO 4027
Product Family
Screw Set Screw
Sub product family
Set Screw HEXA. With Hole
Tip
Cone Point
Diameter in mm
7.972 - 7,772
Unit weight
1.7 GR
1579 Items
3663072163959
Machine Screw Stainless Steel A2 Socket Head Hexagon Recess Hexagon Socket 4 M8X8 Cone Point
Diameter = M8, Length = 8, Sub Product Family = Set Screw HEXA. With Hole, Material = Stainless Steel A2, Pitch = Standard pitch 125, Drive Type = Socket Cap, Norm = DIN 914 ISO 4027, Product Family = Screw Set Screw, Size Drive Type = Hexagon Socket 4


dimensional guide (mm)
Diameter M2 M2.5 M3 M4 M5 ML6 M8 M10 M12 M14 M16 M18 M20 M22 M24 M30
Across flats 0.9 1.3 1.5 2 2.5 3 4 5 6 6 8 10 10 12 12 14

Other Reference : 622058X8 901013204 BP9000808008 14643 1880017 DCXN036 40900062 3663072163959
Michel F. (vis-express.fr)
2024-03-03

screw used in sliding window door lock
