1 x Elastic Pin Zinc Plated 6X20 Thick Series
1 x Elastic Pin Zinc Plated 6X20 Thick Series
1 x Elastic Pin Zinc Plated 6X20 Thick Series
1 x Elastic Pin Zinc Plated 6X20 Thick Series

1 x Elastic Pin Zinc Plated 6X20 Thick Series

7090602002_1
In stock 1087 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included €4.25 €8.45 €14.85 €70.60
Elastic Pin Zinc Plated 6X20 Thick Series
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
6
Length
30
Material
Steel
Coating
ZINC PLATED White
COLOR
Grey
Norm
VS-DIN1481
Product Family
Pin
Sub product family
Elastic Pin
WEIGHT For THERE unit
2.6 GR
1087 Items
3663072231375

Application

  • Assembly of mechanical parts
  • Positioning of shafts and hubs
  • Industrial machinery
  • General mechanics and maintenance
Elastic Pin Zinc Plated 6X20 Thick Series
Diameter = 6, Length = 20, Coating = Zinc Plated, Sub Product Family = Elastic Pin, Material = Steel, Norm = VS-DIN1481, Product Family = Pin


dimensional guide (mm)
diam tre du trou de per age 1 1.5 2 2.5 3 3.5 4 4.5 5 6 7 8 10 12 13 14 16 18 20 21 25 28 30 32 35 38 40
diam tre mini 1.2 1.7 2.3 2.8 3.3 4.4 4.9 5.4 6.4 7.45 8.5 8.5 10.5 12.5 13.4 14.5 16.5 18.5 20.5 21.5 25.5 28.5 30.5 32.5 35.5 38.5 40.5
diam rtre maxi 1.3 1.8 2.4 2.9 3.5 4 4.6 5.1 5.6 6.7 7.8 8.8 10.8 12.8 13.8 14.8 16.8 18.9 20.9 21.9 25.9 - - - - - -
paisseur 0.2 0.3 0.4 0.5 0.6 0.75 0.8 1 1 1.2 1.2 1.5 2 2.5 2.5 3 3 3.5 4 4 5 5.5 6 6 7 7.5 7.5

Other Reference : 3617501940673 VI 672A 1405000004 0GOUPE6-20 6107005 1014948 290263 CO84110.007 549050 3663072231375
