1 x Coach Screws/Hexagonal Head Wood 10X90 Zinc Plated

1 x Coach Screws/Hexagonal Head Wood 10X90 Zinc...

1 x Coach Screws/Hexagonal Head Wood 10X90 Zinc Plated

Name: 1 x Coach Screws/Hexagonal Head Wood 10X90 Zinc Plated
Brand: Screw Express
SKU: 4400109002
Price: 1.85 EUR
Availability: InStock

Reference 4400109002_1

In stock 8738 Pièces

€1.85 Incl VAT

Decreasing prices by quantity

Number of pieces	1	10	30	100	400
Lot price VAT included	€1.85	€3.70	€4.65	€15.50	€53.60

DIN 571 - Coach Screws/Hexagonal Head Wood 10X90 Zinc Plated

Packaging

1 unit
10 units
30 units
100 units
400 Units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Product Details

Diameter: 10
Length

Length

How do I measure the length of a screw?

The length of a countersunk screw is measured with the head. For all other heads, the length is measured under the head.: 90
Material: Steel
Coating: Zinc Plated

Zinc Plated

Zinc plating 3 to 5 µm

All our zinc-plated parts meet this specification (unless otherwise stated).

🛡️ Corrosion protection: low
Thin 3 to 5 µm zinc coating, suitable for environments with low exposure.

🧂 Salt spray resistance: 24 to 96 h
Indicative resistance before the appearance of rust, depending on the coating finish.

🏠 Recommended environment
Indoor applications or environments with very low exposure to moisture.

🔩 Threads preserved
The low coating thickness limits dimensional variations and helps maintain thread accuracy.
COLOR: Grey
Norm: DIN 571
Head thickness: 6.4
Unit weight: 20 GR
Spanner: 17
Width across corners (e): 18.90
Pre-drilling softwood: 6-7 MM
Pre-drilling hardwood: 7-8 MM

In stock 8738 Items

ean13 3663072093751

Description

Coach Screws/Hexagonal Head Wood 10X90 Zinc Plated
Diameter = 10, Length = 90, Coating = Zinc Plated, Material = Steel, Norm = DIN 571

dimensional guide (mm)

Diameter	5	6	7	8	10	12	14	16
Head Tickness	3.5	4	5	5.5	7	8	9	10
Across flats	8	10	12	13	17	19	22	24

Other Reference : 3617500894892 V023108900 TIR1090 18001 ZVISSTIREFON PDV0022A V023108900 V023108900 3663072093751

Use Cases

Cecile H. (vis-express.fr)
2025-06-22

Screwing terrace posts Bricorama brand post section 9cm x 9cm

Jean-Francois L. (vis-express.fr)
2025-05-18

These lag screws are used to assemble chestnut posts and rails to make a rustic fence. I use 10X90 Zinc-plated Steel Lag Screws to assemble 100x50 half-round rails and posts.

Jean-Philippe B. (vis-express.fr)
2025-05-11

These lag screws are used for assembling timber frame walls, in particular the lower rails between them. The section of the uprights is 50 * 100 mm for interior partitions with Fermacell bracing and 50 * 160 mm for walls with AGEPAN.

David L. (vis-express.fr)
2024-06-30

To assemble the MOB 45x220 wood section
