4516804502_1
In stock 13906 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 100
Lot price VAT included €4.25 €8.45 €10.20 €13.30
DIN603 FT VS4516 - Carriage Bolt M8X45 Full Thread Zinc Plated
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 100 units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M8
Length
45
Thread
Full Thread
Pitch
Standard pitch 125
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN603 Full Thread VS4516
Sub product family
Carriage Bolt
Width X Width X Thickness of square collar
8X8X5.6
Diameter in mm
7.972 - 7,772
Unit weight
22.34 GR
13906 Items
3663072097476
Carriage Bolt M8X45 Full Thread Zinc Plated
Diameter = M8, Length = 45, Coating = Zinc Plated, Material = Steel, Pitch = Standard pitch 125, Norm = DIN603 Full Thread VS4516


dimensional guide (mm)
Diameter 5 6 7 8 10 12 14 16
Head diameter 13.5 16.5 18 20.5 24.5 30.5 32 39
Head Tickness 3.3 3.9 4.8 5 5.4 7 10 9

Other Reference : 3473571371201 1140234 525895 15416 VI 417A X86308 0091108046 DIN603.M8X45 P02VZTRCC08X 14330000 21000 BO725 AEJAPY8X45 7074620845 PO2VZTRCC08X 0300080803 JAP08045 500634 703358W CO85132.007 22208045 3663072097476
