4516607502_1
In stock 5830 Pièces
€3.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 100
Lot price VAT included €3.85 €7.70 €9.30 €9.95
DIN603 FT VS4516 - Carriage Bolt M6X75 Full Thread Zinc Plated
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 100 units

Dimensions shown in millimeters (mm)

Diameter
M6
Length
75
Thread
Full Thread
Pitch
Standard pitch 100
Material
Steel
Coating
ZINGUE White
COLOR
Grey
Norm
DIN603 Full Thread VS4516
Sub product family
Carriage Bolt
Width X Width X Thickness of square collar
6X6X4.6
Diameter in mm
5,974 - 5,794
Unit weight
15.69 GR
5830 Items
3663072096806
Carriage Bolt M6X75 Full Thread Zinc Plated
Diameter = M6, Length = 75, Coating = Zinc Plated, Material = Steel, Pitch = Standard pitch 100, Norm = DIN603 Full Thread VS4516


dimensional guide (mm)
Diameter 5 6 7 8 10 12 14 16
Head diameter 13.5 16.5 18 20.5 24.5 30.5 32 39
Head Tickness 3.3 3.9 4.8 5 5.4 7 10 9

Other Reference : 3473571370624 005446805 AEJAPY675 VIJ06 75 VTRCC675 3663072096806
Simon H. (vis-express.fr)
2025-05-04

It will help me to redo my gate I will redo the palines of my gate with the TRCC JAPY screws round head square collar M6X75 Total thread Zinc-plated steel
