1 x Bolt Partial Thread Stainless Steel A2 Hexagonal Head M10X170
1 x Bolt Partial Thread Stainless Steel A2 Hexagonal Head M10X170
1 x Bolt Partial Thread Stainless Steel A2...
1 x Bolt Partial Thread Stainless Steel A2...

1 x Bolt Partial Thread Stainless Steel A2 Hexagonal Head M10X170

8409111718_1
In stock 706 Pièces
€1.85 Incl VAT
Decreasing prices by quantity
Number of pieces 1 5 20 50 200
Lot price VAT included €1.85 €5.35 €21.50 €53.75 €214.90
DIN931,ISO4014,VS4109,VS0100 - Bolt Partial Thread Stainless Steel A2 Hexagonal Head M10X170
Packaging
  • 1 unit
  • 5 units
  • 20 units
  • 50 units
  • 200 units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M10
Length
170
Material
Stainless Steel A2
COLOR
Grey
Norm
DIN931, ISO4014, VS4109, VS0100
Product Family
Bolts Hexagonal Head
Diameter in mm
9.968 - 9.752
Unit weight
115.1 GR
Head shape
Hex Head
Spanner
16
706 Items
3663072156890
Bolt Partial Thread Stainless Steel A2 Hexagonal Head M10X170
Diameter = M10, Length = 170, Material = Stainless Steel A2, Norm = DIN931, ISO4014, VS4109, VS0100, Product Family = Bolts Hexagonal Head


dimensional guide (mm)
Diameter 5 6 8 10 12 14 16 18 20 24 27 30 33
Head Tickness 3.5 4 5.3 6.4 7.5 8.8 10 11.5 12.5 15 17 18.7 21
Across flats 8 10 13 17 19 22 24 27 30 36 41 46 50
Thread if total screw length < 125 16 18 22 26 30 34 38 42 46 54 60 66 72
Thread if total screw length > 125 22 24 28 32 36 40 44 48 52 60 66 72 78
Thread if total screw length > 200 0 0 0 0 0 0 57 61 65 73 79 85 91

Other Reference : 6210210X170 M10*170 H.M10X170.I 9-933A2M10X1 3663072156890
