8721131518_1
In stock 234 Pièces
€4.25 Incl VAT
Decreasing prices by quantity
Number of pieces 1 5 10 25
Lot price VAT included €4.25 €11.65 €23.25 €58.15
DIN931,VS4109,VS0100 - Bolt Partial Thread Hexagonal Head M12X150 Stainless Steel A4
Packaging
  • 1 unit
  • 5 units
  • 10 units
  • 25 units

See all available dimensions in this range Dimensions shown in millimeters (mm)

Diameter
M12
Length
150
Material
Stainless Steel A4
COLOR
Grey
Norm
DIN931, VS4109, VS0100
Product Family
Bolts Hexagonal Head
Diameter in mm
11.966 - 11.718
Unit weight
145 GR
Head shape
Hex Head
Spanner
19
234 Items
3663072173316
Bolt Partial Thread Hexagonal Head M12X150 Stainless Steel A4
Diameter = M12, Length = 150, Material = Stainless Steel A4, Norm = DIN931, VS4109, VS0100, Product Family = Bolts Hexagonal Head


dimensional guide (mm)
Diameter 5 6 8 10 12 14 16 18 20 22 24
Head Tickness 4 4 5.3 6.4 7.5 8.8 10 11.5 12.5 14 15
Across flats 8 10 13 17 19 22 24 27 30 34 36
Thread if total screw length < 125 16 18 22 26 30 34 38 42 46 50 54
Thread if total screw length > 125 22 24 28 32 36 40 44 48 52 56 60
Thread if total screw length > 200 0 0 0 45 49 53 57 61 65 69 73

Other Reference : 6410212X150 S05653 S05653 5231A2364010 S05653 FA60241 13369 3663072173316
Nicolas P. (vis-express.fr)
2024-09-15

This bolt will be used to replace a straight mainsail balus axis which is mounted vertically with a key which c der For a B n teau Oc anis 343 type sailboat.
