3702400829_1
In stock 74190 Pièces
€1.70 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 100 500
Lot price VAT included €1.70 €3.40 €4.05 €10.35
Blind rivets Aluminium Stahlgewinde 4X8 Thickness Of Panel 2 to 4 Flat Head ALX Black
Packaging
  • 1 unit
  • 10 units
  • 100 units
  • 500 Units

Dimensions shown in millimeters (mm)

Diameter
4
Sub product family
Flat Head
WEIGHT For THERE unit
1.6 GR
Clamping thickness
2 to 4 MM
Rivet body length
8
74190 Items
3663072063952
Blind rivets Aluminium Stahlgewinde 4X8 Thickness Of Panel 2 to 4 Flat Head ALX Black
Diameter = 4


dimensional guide (mm)
Body diameter 2.4 3 3.2 4 4.8 6 6.4
Head diameter 5 6 6.5 8 9.5 11.5 12
Drilling diameter 2.6 3.2 3.4 4.2 5 6.2 6.6
resistance a la traction 500 800 1000 1600 2600 3800 4600
Shear strength 400 650 850 1300 2100 3000 3500
longueur tige 25 25 25 27 27 27 27 27

Other Reference : 115140081 RIV4X8N 021.i.tp48n MF0009A MF0009A 221380 VIS0008 VP030013 RIV4X8N 1772000 500 1010A0015 3663072063952
