1 x Bolt Partial Thread Hexagonal Head M12X80...

1 x Bolt Partial Thread Hexagonal Head M12X80 Class 6.8 Zinc Plated

4014128099_1
In stock 5330 Pièces
€3.50 Incl VAT
Decreasing prices by quantity
Number of pieces 1 10 30 200
Lot price VAT included €3.50 €7.05 €15.30 €102.00
din 931 - Bolt Partial Thread Hexagonal Head M12X80 Class 6.8 Zinc Plated
Packaging
  • 1 unit
  • 10 units
  • 30 units
  • 200 units

Dimensions shown in millimeters (mm)

5330 Items
3663072451919
Bolt Partial Thread Hexagonal Head M12X80 Class 6.8 Zinc Plated
Diameter = M12, Length = 80, Coating = ZINGUE White, Sub Product Family = Hex Head, Class = CLASS Class 6.8, Material = Steel, Product Family = Bolts Hexagonal Head


dimensional guide (mm)
Diameter 5 6 8 10 12 14 16 18 20 24 27 30 33
Head Tickness 3.5 4 5.3 6.4 7.5 8.8 10 11.5 12.5 15 17 18.7 21
Across flats 8 10 13 17 19 22 24 27 30 36 41 46 50
Thread if total screw length < 125 16 18 22 26 30 34 38 42 46 54 60 66 72
Thread if total screw length > 125 22 24 28 32 36 40 44 48 52 60 66 72 78
Thread if total screw length > 200 0 0 0 0 0 0 57 61 65 73 79 85 91

Other Reference : 3617500950543 3663072451919
